Backpack Fire Sprayer
Zhenjiang Linhao Forest Fire Prevention Equipment Co., Ltd. is one of the leading manufacturers and suppliers of backpack fire sprayer in China. If you're going to wholesale advanced backpack fire sprayer, welcome to get quotation and free sample from our factory. All customized products are with high quality and low price.
Backpack Fire Sprayer – Efficient and Reliable Firefighting Tool
The Backpack Fire Sprayer is an essential tool for effective fire suppression in remote areas. This manual, mechanical sprayer is designed to tackle fires in forests, grasslands, and during initial firefighting operations. With a lightweight, easy-to-carry design, it allows for seamless firefighting without the need for electricity or batteries.
Here's how it works
1. Suction Action (Pull Back)
- Pulling back the handle creates negative pressure in the pump chamber.
- The one-way intake valve opens, drawing water from the tank.
- The discharge valve remains closed to prevent water from flowing backward.
2. Pressure Action (Push Forward)
- Pushing the handle forward increases pressure in the pump chamber.
- The intake valve closes to prevent reverse water flow.
- The discharge valve opens, allowing high-pressure water to flow through the nozzle.
3. Continuous Spray
- Repeatedly pushing and pulling the handle ensures a continuous water stream, maintaining a stable jet flow.
Key Features
- No Motor or Battery: Fully mechanical, powered by human force.
- Dual One-Way Valves: Ensures water flows in one direction for efficiency.
- Lightweight: Easy to carry, making it perfect for individual use.
Specifications
|
Component |
Details |
|
Water Tank Volume |
≥20L |
|
Sprayer Length |
≤910mm (Extended), ≤590mm (Collapsed) |
|
Sprayer Range |
≥10m |
|
Water Flow |
≥110cm³ |
|
Weight |
≤1.0kg |
|
Sprayer Features |
Adjustable handle with slip-resistant grips |
|
Material |
High-strength, waterproof fabric (backpack); PVC (water tank) |
|
Spray Pattern |
Adjustable: Direct or scattered spray (via nozzle rotation) |
Applications
- Forestry Fires
- Grassland and Prairie Firefighting
- Initial Stage Fire Suppression
- Emergency Rescue
- Remote Locations without Power Supply
The Backpack Fire Sprayer is the perfect solution for efficient, portable firefighting, combining rugged durability with ease of use. Whether it's tackling small fires in remote areas or aiding in emergency rescue efforts, this tool is a reliable choice for professionals.
