Product Overview

Portable and skid-mounted water fire extinguishing equipment engineered for rapid deployment in forest, grassland, and complex outdoor environments. The product range features light-duty portable fire pumps, heavy-duty suppression units, ruggedized fire extinguishers, and precision fire spray nozzles designed to deliver high-pressure water streams where municipal fire infrastructure is unavailable.

Built for tactical field operations, these systems provide reliable transport, high-pressure pressurization, and directional water discharge to establish control lines and suppress active fire zones efficiently.

Ultra High Pressure Fire Pump SF23-4
Ultra High Pressure Fire Pump SF23-4 The Ultra High Pressure Fire Pump SF23-4 combines a four-stage centrifugal pump, speed increaser gearbox and 25 HP gasoline engine. It provides high pressure,...
Petrol Fire Pump
Products Description The Short Version Your water source is muddy, full of leaves, maybe some small rocks. A normal centrifugal pump clogs in ten minutes. This one doesn't. It's a...
Portable Forest Firefighting Pump
Portable Forest Firefighting Pump What It Does Pick it up, sling it on your back, and get water to the fire line fast. This two-stage centrifugal pump runs on a single-cylinder two-stroke engine -...
Wildfire Water Pump
Wildfire Water Pump Product Overview A heavy-duty diaphragm pump built for wildfire suppression and remote field operations. Unlike centrifugal designs, the diaphragm chamber handles muddy,...
Forest Fire Water Pump
Forest Fire Water Pump Product Overview Built for wildfire suppression and remote field operations, this portable fire pump delivers high-pressure water where fixed hydrants cannot reach. A...
High Pressure Water Transfer Pump
High Pressure Water Transfer Pump Powerful High-Pressure Performance The High Pressure Water Transfer Pump is engineered for professional firefighting, wildfire suppression, emergency rescue, and...
Fire Fighting Water Pump
Portable High Pressure Fire Fighting Water Pump for Emergency Rescue High-Pressure Performance for Outdoor Operations In forest fire prevention, firefighting rescue, flood control, mining rescue,...
Portable Wildfire Pump
Portable Wildfire Pump – Lightweight High-Pressure Firefighting Solution The Portable Wildfire Pump is designed for wildfire suppression, emergency rescue, forestry protection, and...
Forest Fire Pump
Forest fire pumps are essential emergency firefighting equipment in forestry, fire rescue, and many other scenarios. With their advantages of high-efficiency pressurization, convenient operation,...
Portable Firefighting Pumps
Portable Firefighting Pumps utilize a high-efficiency centrifugal pressurization principle. The engine drives the impeller to rotate at high speed, quickly creating negative pressure for water...
Water Pump for Fire Fighting
Water pump for fire fighting employs a three-stage centrifugal structure, constructed from corrosion-resistant aluminum alloy, and is driven by a dedicated hybrid-cooled engine. Its core mechanism...
Detachable Four-stage Centrifugal Water Pump
The detachable four-stage centrifugal water pump is suitable for various scenarios such as forestry, fire rescue, flood control and drought relief, and is the preferred equipment for emergency...

First 12 3 Last

Working Principle

The equipment operates by drawing water from natural or mobile sources and discharging it under controlled mechanical pressure to absorb thermal energy from the combustion zone:

Thermal Energy Absorption:

High-velocity water streams break down into fine droplets or heavy spray patterns, rapidly extracting heat from burning solid fuels.

Direct Surface Penetration:

Pressurized delivery ensures water penetrates deep-seated embers in forestry and grassland applications, preventing reignition.

Flow & Directional Control:

Spray nozzles allow operators to dynamically adjust discharge patterns from straight stream (for long-range reach) to wide fog (for personal heat shielding and blanket cooling).

Product Types

Light-Duty Fire Pumps:

Portable, gasoline- or diesel-driven units designed for rapid manual deployment by single or dual operators in remote, uneven terrain.

Heavy-Duty Fire Pumps:

High-capacity, skid- or trailer-mounted systems engineered for sustained, high-volume water delivery and continuous multi-hose operation.

Fire Extinguishers:

Pressurized, portable water-based extinguishers tailored for rapid initial response and localized spot fires.

Fire Spray Nozzles:

Heavy-duty shut-off nozzles engineered to withstand high working pressures and regulate water distribution patterns in the field.

Key Features

High Power-to-Weight Ratio: Portable pump frames optimized for easy manual carrying or ATV transport across rugged forest terrain.

Extended Suction Capability: Engineered with high-lift self-priming capabilities to draw water efficiently from natural sources such as rivers, lakes, or portable tanks.

Corrosion-Resistant Fluid Pathways: Pump casings manufactured from high-grade anodized aluminum alloys or stainless steel components to resist water-borne sediment wear.

Standardized Hose Connections: Equipped with globally recognized threaded or quick-disconnect couplings for seamless field integration.

Dual Operational Modes: Adjustable pressure-flow regulators allowing operators to switch between high-pressure distance throwing and high-volume wetting.

Materials & Construction / Components

Durability in aggressive outdoor environments requires strict material tracking and robust structural design:

Component	Standard Specification	Field Application Benefit
Pump Casing & Volute	Hard-Anodized Aluminum Alloy	High tensile strength with minimal weight for transport; high resistance to abrasion from silty water.
Impeller & Shaft	Bronze / 304 Stainless Steel	Prevents electrochemical corrosion and maintains hydraulic efficiency under high rotational speeds.
Carrying Frame / Skid	Welded Tubular Steel with Powder Coating	Withstands rough handling, drops, and vehicle vibration during transport.
Sealing & Gaskets	NBR / Viton Elastomers	Tolerates broad temperature swings and resists degradation from chemical foam additives.

Technical Specifications

Specification Parameter	Standard Engineering Range / Description
Operating Pressure Range	0.5 MPa to 2.5 MPa (Model dependent: High-pressure vs. Volume-focused variants)
Flow Rate Capacity	50 L/min to 600 L/min
Maximum Suction Lift	Up to 6 meters (with proper priming and foot valve configuration)
Power Units	Air-cooled 4-stroke gasoline engines or heavy-duty diesel engines with electric/recoil start
Inlet / Outlet Port Sizes	1.5-inch to 2.5-inch standard thread configurations
Ambient Operating Range	-15°C to +50°C

Applications

Forestry & Wildfire Suppression:

Establishing firebreaks, wetting down perimeter vegetation, and direct attack on active forest fires.

Grassland Fire Response:

Rapid mobilization on utility vehicles or trailers to suppress fast-moving grass and brush fires.

Remote Emergency Rescue:

Delivering supplemental water supply in off-grid locations where municipal hydrants are inaccessible.

Agricultural & Field Water Transfer:

Dual-purpose utility for emergency irrigation or filling mobile water tender trucks during dry seasons.

Manufacturing & Quality Control

Production adheres to rigorous industrial fabrication and assembly standards to ensure field reliability:

Precision CNC Machining:

Component tolerances for pump impellers and housings maintained via 5-axis machining centers to optimize hydraulic performance.

Dynamic Balancing:

Rotating pump assemblies undergo dynamic balancing to eliminate vibration during high-RPM operation.

Hydrostatic Pressure Testing:

Every pump casing and manifold undergoes a 1.5x working pressure test prior to final assembly.

Dry-Run & Flow Bench Testing:

Finished pump units are subjected to bench testing to verify engine stability, priming speed, and rated flow output.

Customization & OEM

Project-specific tailoring available for government tenders, fleet operators, and specialized OEM partners:

Engine Configuration: Selection of specific power units based on regional emission and fuel availability standards.

Coupling Customization: Integration of regional thread standards on inlet and discharge ports.

Skid Dimensions & Frame Layouts: Structural footprints adjusted for specific vehicle bed mounts, fire carts, or ATV racks.

Branding & Documentation: Custom stenciling, user manuals in local languages, and specific compliance labeling.

Selection Guide

Evaluate these core engineering variables when specifying equipment for your project:

Water Source Proximity: Determine maximum suction lift and distance from the water source to select the correct pump head and horsepower.

Terrain & Mobility Needs: Choose lightweight portable backpack/frame pumps for manual access, or heavier skid units for vehicle-borne deployment.

Flow vs. Pressure Balance: High-pressure units are preferred for long hose lays up steep inclines; high-volume units suit rapid saturation of flat terrain.

Accessory Compatibility: Verify that hose diameters, nozzle thread types, and strainer sizes match existing inventory.

Frequently Asked Questions

Q: What is the maximum suction lift for the portable fire pumps?

A: Standard portable pumps achieve a maximum practical suction lift of up to 6 meters at sea level, provided a tight foot valve and primed suction hose are used. Suction efficiency decreases at higher altitudes.

Q: Can these pumps handle water mixed with firefighting foam or retardants?

A: Yes. The wetted internal components utilize corrosion-resistant aluminum alloys and elastomer seals compatible with standard Class A fire suppressant foams and wetting agents.

Q: What is the standard lead time for custom OEM pump configurations?

A: Standard production runs require 3 to 4 weeks. Custom specifications involving specialized engine types, unique frame dimensions, or third-party inspections typically range from 6 to 8 weeks.

Q: Are the portable pumps easy to start in cold weather environments?

A: Yes. Units are equipped with reliable recoil or electric-start engines featuring manual choke controls designed to operate down to -15°C with proper seasonal fuel formulations.

Q: What quality documentation is supplied with the shipment?

A: Each delivery includes factory test performance reports (flow/pressure curves), material compliance confirmation for critical components, engine certificates, and a comprehensive operation and maintenance manual.

Q: What details should be provided when requesting an official quotation?

A: Please provide the intended application (e.g., forest wildfire vs. grassland), required flow rate and pressure, preferred power type (gasoline/diesel), connection thread standards, destination port, and any specific quantity or OEM requirements.
