Turbojet Fire Extinguisher
Zhenjiang Linhao Forest Fire Prevention Equipment Co., Ltd. is one of the leading manufacturers and suppliers of turbojet fire extinguisher in China. If you're going to wholesale advanced turbojet fire extinguisher, welcome to get quotation and free sample from our factory. All customized products are with high quality and low price.
Turbojet Fire Extinguisher: Advanced Firefighting Technology
The Turbojet fire extinguisher is an innovative firefighting device that combines the power of a turbojet engine with high-pressure water mist to efficiently suppress fires. This cutting-edge system offers fast, precise, and highly effective fire suppression, making it ideal for use in forestry, rescue operations, and urban fire management.
Working Principle
- Power Drive: The system is powered by a high-speed turbojet engine that drives a centrifugal fan.
- High-Speed Airflow: The rotating fan generates airflow at speeds of up to 190 m/s, creating an intense jet stream.
- Water Atomization: A pump or siphon system draws in water, which is then atomized into fine mist by the high-speed air.
- Vortex Jet Extinguishing: The combination of air and water forms a high-velocity, rotating jet that effectively blows away flames, reduces temperature, and suffocates oxygen, rapidly extinguishing the fire.
Key Features
- Efficient Fire Suppression: The combination of high-speed air and water mist provides quicker cooling and suffocation, making it more effective than using air or water alone.
- Long Range and Strong Penetration: With airflow speeds up to 190 m/s, it can reach distant fire sources with strong penetration.
- Portable Design: Available in both backpack and handheld versions, it is ideal for use in remote or mountainous areas.
- Rapid Response: This system immediately lowers temperatures and suppresses flames, making it effective for surface fires, crown fires, and other emergencies.
Technical Specifications
|
Parameter |
Value |
|
Extinguishing Range |
≥15 meters |
|
Airflow Speed |
≥210 m/s |
|
Water Flow |
≥12.5 L/min |
|
Maximum Spray Height |
≥10 meters |
|
Water Tank Volume |
≥22L |
|
Machine Weight |
≤6.5 kg |
|
Fuel Type |
Diesel + Engine Oil mixture |
|
Battery |
7.4V LiPo 2500mAh, 11.1V LiPo 2200mAh |
The Turbojet fire extinguisher is an efficient, fast-response firefighting tool that offers high performance in challenging environments. Its portability, power, and effectiveness make it a valuable asset for firefighting teams worldwide.
